SPECIFICATIONS
INPUT SENSITIVITY/IMPEDANCE
MIC 1-2: 1.5mV/600 ohms,
         balance/unbalance.
Phono 1/2/3: 3.0mV/50K ohms.
Line 1-8: 150mV/27K ohms.
OUTPUT LEVEL
Master output: 2.0V/10K ohms.
Zone output: 2.0V/10K ohms.
Record output:150mV/10K ohms.
FREQUENCY RESPONSE
20Hz to 20K Hz  ±3dB
CHANNLE EFFECT

Digial sampler with 5 meomory

banks 24 seconds digital sampling.
SIGNAL RATIO
MIC: >60 dB/1.5mV input
Phono: >70dB/3.0mV input
Line: >80dB/150mV input
DISTORTION
MIC:0.20%
Phono:0.05%
Line:0.03%
EQUALZER
Control frequencies:63,100,400,1K,2.5K,6.3K, 16K
Boost/cut range: ±12dB from center.
MIC EQ CONTROL
HIGH tone:10k hZ+10/-30dB
Middle tone:1K Hz+10/-30dB
Low tone:100 Hz±10/-30dB
TALKOVER ATTENUATION
-16dB
POWER SOURCE
Power voltage: 115V AC /230V AC
Frequency:50Hz/60Hz
