INPUT SENSITIVITY/IMPEDANCE
MIC 1-4: 1.5mV/600 ohms,
         balance/unbalance.
Phono 1-2: 3.0mV/50K ohms.
Line 1-8: 150mV/27K ohms.
Return EFX:500mV/10K ohms.
OUTPUT LEVEL
Master output: 2.0V/1K ohms.
Zone output: 2.0V/1K ohms.
Record output:300mV/10K ohms.
Send EFX: 500mV/10K ohms.
FREQUENCY RESPONSE
20Hz to 20K Hz  +0,-3dB
CHANNLE EFFECT
6-Audio effect
S/N RATIO (at 1K Hz)
MIC: >60 dB/1.5mV input
Phono: >70dB/3.0mV input
Line: >80dB/150mV input
DISTORTION
MIC:0.20%
Phono:0.05%
Line:0.03%
EQUALZER
Control frequencies:30,60,120,250,500,1K,2K,4K,8K,and 16K Hz
Boost/cut range:+/-12dB from center.
CHANNEL EQ CONTROL
HIGH tone:10k hZ+/-15dB
Middle tone:1K Hz+/-15dB
Low tone:100 Hz+/-15dB
TALKOVER ATTENUATION
Fader 16dB
POWER SOURCE
Power voltage: AC 115V/230V
Frequency:60Hz/50Hz
